High Pressure Gas Compressors

High Pressure Gas Compressors

SHINEEAST Gas Compressors are widely used in kinds of industries and testing equipments, with output pressure up to 400 bar.

SHINEEAST Gas Compressors are widely used in kinds of industries and testing equipments, with output pressure up to 400 bar.

The output pressure of the gas compressors is 10-400bar, with output flow max. 1200m³/hr; the power is from 2.2KW to 75KW, including single stage compression and double stage compression.

The gas compressor can be used for nitrogen gas, helium gas, methane, CO2, argon gas, dry air etc.


Technical parameters:
GL Series gas compressor:

SpecificationOutlet pressure (MPa)Inlet pressure (MPa)Flow(m³/hr)Motor power (KW)
ST10-2.2-GL101.4-108-602.2
ST10-4-GL101.4-1014-1004
ST10-7.5-GL101.4-1025-1807.5
ST10-11-GL101.4-1040-30011
ST10-15-GL101.4-1055-38015
ST10-30-GL101.4-10110-78030
ST10-45-GL101.4-10170-120045
ST20-2.2-GL202.8-207-552.2
ST20-4-GL202.8-2012-904
ST20-7.5-GL202.8-2024-1807.5
ST20-11-GL202.8-2040-28011
ST20-15-GL202.8-2050-36015
ST20-30-GL202.8-20110-75030
ST20-45-GL202.8-20160-110045
ST40-2.2-GL405.5-406-452.2
ST40-4-GL405.5-4010-804
ST40-7.5-GL405.5-4020-1507.5
ST40-11-GL405.5-4036-24011
ST40-15-GL405.5-4045-32015
ST40-30-GL405.5-40100-65030
ST40-45-GL405.5-40150-100045
